- Commodity name: JB-QB-F53 User information transmission device
JB-QB-F53 user information transmission device has the characteristics of rich operation functions, convenient connection and good real-time performance, which can be applied to all kinds of networking projects. Is in line with the GB26875.1-2011 "Urban fire remote Monitoring system Part I: User information transmission device" standard, GB/T 19001-2008 "Quality Management system requirements" and "fire products 3C certification implementation Rules" a user information transmission device. It adopts wall hanging structure, easy to install to meet the needs of the site. JB-QB-F53 user information transmission device is based on 32-bit ARM chip as the software platform, the software stability is good, the modular design structure is easy to software upgrade, and at the same time with TCP/IP, 4G communication mode and LCD screen.

Main Features

Supports TCP/IP networking. The information is transmitted to the monitoring center through the local area network or the wide area network.
The configuration software of PC is used to set up the JB-QB-F53 transmission device through the serial interface.
LED lights display the controller and the state of the machine, each key operation is convenient and quick.
Simple and generous appearance, display controller and the state of the machine, easy to operate.
Instead of relying on the fire alarm controller, the duty officer sends an emergency alarm signal to the monitoring center directly through this device.
The administrator of the city fire automatic alarm monitoring center can check the on-duty status of the fire duty personnel of a network unit according to the pre-set time or at any time through the device.
The fire workstation of the city fire automatic alarm monitoring center must have a fixed IP address.
"Self-check", "reset", "mute", "check response", "manual alarm" and other operations can be carried out on site.
Wide power supply voltage range, own backup power.
The equipment in the fire, fault and check, shielding have different sound prompts, press the "mute" key, eliminate the alarm sound
It CAN be connected to the fire alarm controller through CAN bus and switch quantity signal. When connecting through serial port, it is required that the relevant information of fire alarm controller can be output through the corresponding serial port, and the manufacturer needs to provide the communication protocol.
Provides 2 switch output (default public alarm, public fault). It can be connected to building fire protection equipment. Public alarm refers to manual alarm and downlink fire alarm; Common faults: local faults and downlink faults.
Can receive 4 switch input signal.
Two RS485 ports, two RS232 ports and two CAN ports are provided to connect with building fire fighting equipment (agreement provided by the manufacturer is required).

text-align: center;" > Operating voltage	AC 220V± 15% 50Hz
Liquid crystal	3.5
Communication mode	CAN, RS485, RS232, TCP/IP, 4G
Power consumption	< 20W
Use environment	Temperature: 0℃ ~ 40℃, relative humidity: ≤ 95% RH (40 + 2 ℃)
Installation mode	Wall hanging
Maximum overall size	26019559mm (length * height * thickness)
Weight	2.52 Kg
